E2E-S05N03-WC-B2 5M: Omron Pre-wired 5M Cable Sensor
Technical Specifications of Omron Pre-wired 5M Cable Sensor E2E-S05N03-WC-B2 5M:
| Spec | Value |
|---|---|
| Sensing head size | M5 |
| Mounting type | Unshielded |
| Sensing distance | 3 mm |
| Connection method | Pre-wired Models (5 m) |
Omron Pre-wired 5M Cable Sensor E2E-S05N03-WC-B2 5M Technical Specifications:
| Specification | Value |
|---|---|
| Sensing head size | M5 |
| Power source | DC 3-wire, |
| Mounting type | Unshielded |
| Sensing distance | 3 mm |
| Connection method | Pre-wired Models (5 m) |
| "Cable specifications" | PVC |
| Output | PNP open collector |
| Operation mode | Normally closed (NC) |
| Response frequency | 2 kHz |
| Power supply voltage | 10 to 30 VDC |
| Current consumption | 10 mA max. |
| Degree of protection | IEC: IP67 Company standard: Oil-proof |
| Weight | Approx. 40 g |
Ask for the Pricing of Omron Pre-wired 5M Cable Sensor E2E-S05N03-WC-B2 5M at unbeatable prices. Detailed Specifications of E2E-S05N03-WC-B2 5M feature M5, Unshielded mounting, 3 mm Sensing Distance, Pre-wired Models (5 m), PVC cable, DC 3-wire, power source, PNP open collector output, Normally closed (NC), 2 kHz frequency, 10 to 30 VDC power Supply, 10 mA max., current consumption. Now's the Time to Secure a Quote for your requirement of Omron Pre-wired 5M Cable Sensor. We're committed to offering more favorable pricing and more responsive support than other Traders.
