E2E-S05N03-MC-B2: Omron M8 Connector with PNP Sensor
Technical Specifications of Omron M8 Connector with PNP Sensor E2E-S05N03-MC-B2:
| Spec | Value |
|---|---|
| Sensing head size | M5 |
| Mounting type | Unshielded |
| Sensing distance | 3 mm |
| Connection method | M8 Connector Models |
Omron M8 Connector with PNP Sensor E2E-S05N03-MC-B2 Technical Specifications:
| Specification | Value |
|---|---|
| Sensing head size | M5 |
| Power source | DC 3-wire, |
| Mounting type | Unshielded |
| Sensing distance | 3 mm |
| Connection method | M8 Connector Models |
| "Cable specifications" | - |
| Output | PNP open collector |
| Operation mode | Normally closed (NC) |
| Response frequency | 2 kHz |
| Power supply voltage | 10 to 30 VDC |
| Current consumption | 10 mA max. |
| Degree of protection | IEC: IP67 Company standard: Oil-proof |
| Weight | Approx. 15 g |
Please speak to our Technical Engineer for Omron M8 Connector with PNP Sensor E2E-S05N03-MC-B2 at attractive prices. Technical Specs Summary of E2E-S05N03-MC-B2 includes M5, Unshielded mounting, 3 mm Sensing Distance, M8 Connector Models, DC 3-wire, power source, PNP open collector output, Normally closed (NC), 2 kHz frequency, 10 to 30 VDC power Supply, 10 mA max., current consumption. Match Your Needs with a Quote for your requirement of Omron M8 Connector with PNP Sensor. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
