E2E-C03SR8-WC-B1 5M: Omron PNP Pre-wired Compact Sensor
Technical Specifications of Omron PNP Pre-wired Compact Sensor E2E-C03SR8-WC-B1 5M:
| Spec | Value |
|---|---|
| Sensing head size | 3 dia. |
| Mounting type | Shielded |
| Sensing distance | 0.8 mm |
| Connection method | Pre-wired models (5 m) |
Omron PNP Pre-wired Compact Sensor E2E-C03SR8-WC-B1 5M Technical Specifications:
| Specification | Value |
|---|---|
| Sensing head size | 3 dia. |
| Power source | DC 3-wire, |
| Mounting type | Shielded |
| Sensing distance | 0.8 mm |
| Connection method | Pre-wired models (5 m) |
| "Cable specifications" | PVC |
| Output | PNP open collector |
| Operation mode | Normally open (NO) |
| Response frequency | 5 kHz |
| Power supply voltage | 10 to 30 VDC |
| Current consumption | 10 mA max. |
| Degree of protection | IEC: IP67 Company standard: Oil-proof |
| Weight | Package: Approx. 25 g |
Get A Quote for Omron PNP Pre-wired Compact Sensor E2E-C03SR8-WC-B1 5M at unbeatable prices. Detailed Specifications of E2E-C03SR8-WC-B1 5M feature Cylindrical type, 3 dia., Shielded mounting, 0.8 mm Sensing Distance, Pre-wired models (5 m), PVC cable, DC 3-wire, power source, PNP open collector output, Normally open (NO), 5 kHz frequency, 10 to 30 VDC power Supply, 10 mA max., current consumption. Match Your Needs with a Quote for your requirement of Omron PNP Pre-wired Compact Sensor. Our pricing and support are unrivaled, especially when compared to other Distributors.
