E2B-M18KS05-M1-C1: Omron Non-Flush type Proximity Sensor
Technical Specifications of Omron Non-Flush type Proximity Sensor E2B-M18KS05-M1-C1:
| Spec | Value |
|---|---|
| Size | M18 |
| Mounting Type | Flush | Shielded |
| Output Type | NPN |
| Connection Method | M12 Connector |
Omron Non-Flush type Proximity Sensor E2B-M18KS05-M1-C1 Technical Specifications:
| Specification | Value |
|---|---|
| Size | M18 |
| Mounting type | Flush | Shielded |
| Sensing Distance | 5 mm |
| Connection method | M12 Connector |
| Body Length | Short body |
| Response frequency | 600 Hz |
| Power supply | 10 to 30 VDC |
| Current consumption | 10 mA max. |
| Output type | NPN |
| Operation mode | NO |
| Overall length | 59 mm |
| Thread length | 39 mm |
| Material housing | Brass, nickel plated |
| Degree of protection (IP) | IP67 |
IndMALL Automation Dealing offers Omron Non-Flush type Proximity Sensor E2B-M18KS05-M1-C1 at attractive prices. Key Technical Features of E2B-M18KS05-M1-C1 are M18 diameter, Flush | Shielded mounting, 5 mm Sensing Distance, M12 Connector, Short body, 10 to 30 VDC power Supply, 3-wire NPN, NO output, IP67 degree of protection. Navigate Your Needs with a Quote for your requirement of Omron Non-Flush type Proximity Sensor. We excel in offering more cost-effective and supportive solutions than other Competitors.
